Cupra Leon Estate 1.4 eHybrid VZ2 Design Edition 5dr DSG

Summary

• Doors: 5
• Fuel Delivery: TURBO DIRECT INJECTION
• Transmission: Semi-auto
• Fuel Type: Hybrid Petrol
• Engine Capacity - CC: 1395
• Trim: VZ2 Design Edition
• Price: £42,740
• Battery Capacity: 12.8
• Engine Power - BHP: 245
• Acceleration: 7
• Top Speed: 140 mph
• Length: 4657 mm
• Width: 1799 mm
• Height: 1463 mm
• Luggage Capacity (Seats Up): 470 l
• Minimum Kerbweight: 1629 kg

Equipment

Driver Convenience

• CUPRA drive profile selection with 4 modes (Comfort/Cupra/Sport/Individual), throttle response and gearshift mode
• Digital cockpit
• E-call
• Four x USB Type C ports (2 in front and 2 in rear)
• Front assist with forward collision warning braking reaction to vehicles, pedestrians and cyclists
• Full link smartphone integration with Mirror Link, wireless Apple CarPlay and wired Google Android Auto
• Lane assist
• Lockable tailgate
• Park assist (inc front/rear parking sensors)
• Rear view camera
• RPM, trip computer, outside temp gauge, instrument light brightness, low fuel warning light, lights on reminder, gearshift indicator
• Service interval indicator
• Start/stop system with regenerative braking
• Wireless phone charger

Engine/Drivetrain/Suspension

• 10 amp mode 2 charging cable
• 16 amp mode 3 charging cable
• 3.6 kw On-board charger
• Standard suspension
• XDS electronic differential lock and dynamic traction support

Entertainment

• Auxiliary input socket

Exterior Features

• Auto dimming rear view mirror
• Body colour door handles
• Body coloured bumpers
• Cupra sports bumpers
• Dark tinted rear windows
• Electric front/rear windows
• Electrically adjustable, heated and folding door mirrors
• Gloss black roof rails
• LED front fog lamps with cornering function
• LED headlights with dynamic turn signals, tail lights, rear fog lights with rear coast to coast lighting
• Panoramic sunroof
• Rain sensing wipers
• Rear diffuser with twin exhaust pipe on each side with simulated exhausts
• Rear side wing doors
• Rear wash/wipe
• Separate daytime running light with automatic headlight control and coming home feature
• Third brake light

Interior Features

• 12v power supply in centre console
• 12v socket in loadspace
• 3 seat bench in 2nd row
• 5 headrests
• 60/40 split rear bench seat with armrest
• Ambient lighting (glovebox, footwell, ambient lighting multicoloured)
• Black headlining
• CUPRA Leather flat bottomed, heated, perforated steering and gearshift paddles
• Cupra sports pedals
• Driver/passenger manual seat height adjustment
• Dust/pollen filter
• Front and rear reading lights X 4
• Front centre armrest
• Front seats manual lumbar adjustment
• Height/reach adjust steering wheel
• Illuminated interior front door sills
• Interior wraparound lighting
• ISOFIX points in outer rear seats with top tether anchorage points
• Luggage tie-down hooks
• PVC/Cloth upholstery with copper stitching + Cupra embossed logo on headrest
• Single front passenger seat
• Sliding boot cover
• Sports bucket seats
• Storage pockets on rear of front seats
• Sunvisors with illuminated mirror
• Three zone climate control

Packs

• Design pack - Cupra Leon
• Dynamic and comfort pack - Leon Cupra
• Media system plus with navigation pack - Leon Cupra

Passive Safety

• 3 point seatbelts on all rear seats
• ABS
• Brake control system - ESC and brake booster
• Child proof door locks
• Cupra black brake calipers
• Driver and front passenger airbags with front passenger airbag de-activation, front side and curtain airbags
• Electronic parking brake
• Extended safety system - seat belt tensioner, window closure and hazard lights
• Hill hold control
• Rear disc brakes
• Seat belt reminder for front and rear seats
• Tiredness recognition system
• Tyre pressure monitoring system

Security

• Anti theft alarm system with interior monitoring in cab, backup horn and towing protection
• KESSY Advanced - Keyless start, keyless entry
• Locking wheel bolts

Trim

• Chrome and copper interior detailing

Wheels

• 19" Performance satin black and copper alloy wheels with 91Y tyres
• Breakdown kit
• Tool kit

Technical

Electric Vehicle Data

• Battery Capacity % guaranteed under warranty: 70
• Battery Capacity in kWh: 12.8
• Battery Charging Scenario 1 - Charge Time (Mins): 300
• Battery Charging Scenario 1 - Percentage Change: 0-100
• Battery Charging Scenario 1 - Power Supply - kW: 2.3
• Battery Charging Scenario 2 - Charge Time (Mins): 213
• Battery Charging Scenario 2 - Percentage Change: 0-100
• Battery Charging Scenario 2 - Power Supply - kW: 3.6
• Battery Leased: No
• Battery Type: Lithium-ion
• Charging Port Location: Left Side Front
• Coupler/Connector Type: Type 2
• Maximum Charging Rate - kW: 3.6
• Standard manufacturers Battery warranty - Mileage: 100000
• Standard manufacturers Battery warranty - Years: 5
• Usable Battery Capacity: 12.8
• WLTP - EC (kWh/100km) - Comb: 15.7
• WLTP - EC (kWh/100km) - Comb - TEH: 15.8
• WLTP - EC (kWh/100km) - Comb - TEL: 15.3
• WLTP - EC (miles/kWh) - Comb: 4
• WLTP - EC (miles/kWh) - Comb - TEH: 3.9
• WLTP - EC (miles/kWh) - Comb - TEL: 4.1
• WLTP - EC AC Weighted (kWh/100km) - Comb: 15.7
• WLTP - EC AC Weighted (miles/kWh) - Comb: 4
• WLTP - Equivalent AER (km) - Comb: 58
• WLTP - Equivalent AER (km) - Comb - TEH: 57
• WLTP - Equivalent AER (km) - Comb - TEL: 59
• WLTP - Equivalent AER (miles) - Comb: 36
• WLTP - Equivalent AER (miles) - Comb - TEH: 35
• WLTP - Equivalent AER (miles) - Comb - TEL: 36

Emissions - ICE

• NOx: 0.014
• Standard Euro Emissions: EURO 6

Emissions - PHEV

• WLTP - CO2 Ch Sus (g/km) - Extra High: 150
• WLTP - CO2 Ch Sus (g/km) - High: 120
• WLTP - CO2 Ch Sus (g/km) - Low: 218
• WLTP - CO2 Ch Sus (g/km) - Medium: 123
• WLTP - CO2 Weighted (g/km) - Comb: 30
• WLTP - CO2 Weighted (g/km) - Comb - TEH: 31
• WLTP - CO2 Weighted (g/km) - Comb - TEL: 30

Engine and Drive Train

• Catalytic Convertor: Yes
• Engine capacity (cc): 1395
• Compression Ratio: 10.0:1
• Cylinder Layout: IN-LINE
• Cylinders: 4
• Cylinders - Bore (mm): 74.5
• Cylinders - Stroke (mm): 80
• Engine Layout: FRONT TRANSVERSE
• Gears: 6 SPEED
• Number of Valves: 16
• Transmission: SEMI-AUTO

Fuel Consumption - PHEV

• WLTP - FC Ch Sus (l/100km) - Comb: 6.4
• WLTP - FC Ch Sus (l/100km) - Extra High: 6.6
• WLTP - FC Ch Sus (l/100km) - High: 5.3
• WLTP - FC Ch Sus (l/100km) - Low: 9.6
• WLTP - FC Ch Sus (l/100km) - Medium: 5.4
• WLTP - FC Ch Sus (mpg) - Comb: 44.1
• WLTP - FC Ch Sus (mpg) - Extra High: 42.8
• WLTP - FC Ch Sus (mpg) - High: 53.3
• WLTP - FC Ch Sus (mpg) - Low: 29.4
• WLTP - FC Ch Sus (mpg) - Medium: 52.3
• WLTP - FC Weighted (l/100km) - Comb: 1.3
• WLTP - FC Weighted (l/100km) - Comb - TEH: 1.4
• WLTP - FC Weighted (l/100km) - Comb - TEL: 1.3
• WLTP - FC Weighted (mpg) - Comb: 217.3
• WLTP - FC Weighted (mpg) - Comb - TEH: 201.8
• WLTP - FC Weighted (mpg) - Comb - TEL: 217.3

General

• Generation Mark: 4
• Insurance Group 1 - 50 Effective January 07: 28E
• Manufacturers Corrosion Perforation Guarantee - Years: 12
• Manufacturers Paintwork Guarantee - Years: 3
• NCAP Adult Occupant Protection %: 91
• NCAP Child Occupant Protection %: 88
• NCAP Overall Rating - Effective February 09: 5
• NCAP Pedestrian Protection %: 71
• NCAP Safety Assist %: 80
• Service Interval Frequency - Months: 24
• Service Interval Mileage: 18600
• Standard manufacturers warranty - Mileage: 90000
• Standard manufacturers warranty - Years: 5
• Vehicle Homologation Class: M1

Performance

• 0 to 62 mph (secs): 7
• Engine Power - BHP: 245
• Engine Power - RPM: 5000
• Engine Torque - NM: 400
• Engine Torque - RPM: 1550
• Top Speed: 140 mph

Test Cycles

• RDE Certification Level: RDE 2

Tyres

• Space Saver?: No
• Tyre Size Front: 235/35 R19
• Tyre Size Rear: 235/35 R19
• Tyre Size Spare: TYRE REPAIR KIT
• Wheel Style: PERFORMANCE
• Wheel Type: 19" ALLOY

Vehicle Dimensions

• Height: 1463 mm
• Length: 4657 mm
• Wheelbase: 2681 mm
• Width: 1799 mm
• Width (including mirrors): 1992 mm

Weight and Capacities

• Fuel Tank Capacity (Litres): 40
• Gross Vehicle Weight: 2090 kg
• Luggage Capacity (Seats Up): 470 l
• Max. Loading Weight: 461 kg
• Max. Towing Weight - Braked: 1700
• Max. Towing Weight - Unbraked: 750
• Minimum Kerbweight: 1629 kg
• No. of Seats: 5
• Turning Circle - Kerb to Kerb: 10.5 m
